    350x300 Mm Cutting Area PCB V Cut Machine PCB Depanelizer WIth Windows OS

    Ask Lasest Price
    Brand Name : Seprays
    Model Number : ZM320
    Certification : CE
    Price : USD1980-30000
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 500 sets per Month
    Delivery Time : 30-45 days
    • Product Details
    • Company Profile

    350x300 Mm Cutting Area PCB V Cut Machine PCB Depanelizer WIth Windows OS

    350x300 Mm Cutting Area PCB V Cut Machine PCB Depanelizer WIth Windows OS
    Dual Worktables Iron PCB Cutting Machine High Speed 350*300mm Cutting Area ZM320

    PCB V Cut Machine Features:
    Equipped with high-speed CCD vision alignment system in all series of products to enhance the precision in cutting and efficiency in operation.
    Use high-speed spindle with small cutting stress to precisely cut PCB of any shape.
    Provide dual worktables.While one is used for cutting,the other can be used for loading to enhance efficiency of production.
    Patented dust collector with low noise and high efficieny. Easy to clean and maintain.
    Windows OS and window-based interface panel. Safe, stable, easy to learn and operate.

    PCB V Cut Machine Specification

    ITEMZM320
    Valid Cutting Area350*300mm
    Cutting FunctionTweening to Line,L-Shape,U-shape,Circle,Arc
    Process TableDual Tables
    Repeat Precision±0.01mm
    Cutting Precision≦±0.05mm
    Max.Moving SpeedXY:1000mm/sec,Z:500mm/sec
    Max.Moving TripX:810mm,Y:370mm,Z:90mm
    Spindle SpeedMAX60,000rpm
    Voltage/Power RequirementAC220V 50/60HZ 2.2KW Single Phase
    Cutting Speed1-100mm/s Adjustable
    Operation SystemWindows10
    Program Teaching MethodIntuitive Teaching by CCD Color Image Input
    Program BackupUSB
    Control MethodPrecision Multi-axis Control System
    XYZ-Axis Driving ModeAC Servo Motor
    Size of Millng Bitφ0.8-3.0mm
    Machine Dimension1245w*1315D*1550H(mm)
    Machine Weight500KG
    Dust CollectorTS200


    Operation Panel
    Operation interface is clear, friendly, and simple. Easy to learn and start quickly.
    Functional items are clear and well categorized. Very easy to set the parameters for milling tool and fixture.
    Provide four levels of autorization control according to user's job rank.
    The "History Window" can display the historical records of operation.


    Dual Workatables
    Provide dual workatables so that placing one PCB and cutting other PCB can be performed in parallel to minimize the waiting time.
    The dual worktables can be merged to form a single large worktable to extend the size of the cutting area. Suitable for cutting large-sized PCBA.
    Adding safety light curtain is available (optional).


    Dust Collection Mechanism
    The"lower dust collector"is included in standard configuration. The "upper dust collector"is available based on the need (optional).


    Vision-Aided Position Calibration
    Use computer vision with high-quality CCD to automatically position the mark points and enhance the accuracy of cutting
    Can edit the path-planning program and simulate the cutting path to avoid wrong cutting.


    Spindle
    High-speed precision spindle (60000RPM).
    Low stress in cutting contact. Generate smooth edge for PCB.
    Automatic compensation function in Z-axis to adjust the cutting depth of milling tool and prolong the life-cycle of the tool.
    Mechanism of detecting broken milling tool is available. ( optional )


    The Whole PCB Scanning Function For Editing the Cutter's Routing Path
    The function of scanning the whole PCB allows the user to facilitate correcting and editing the cutter's routing path rapidly.


    Application:
    Equipped with high efficient vision-aided position alignment system with high-speed CCD camera in all product series .Especially desinged for high-precision and high-production PCB cutting process.
    Suitable for de-paneling small-sized PCB for cell phone, digital camera, GPS device, and PDA, etc.
    Can choose either standard fixture or customized fixture for PCB cutting to help increasing the production volume.
    Provide dual worktables so that placing and cutting PCB can be performed simultane-ously to minmize the waiting time.
