Handy Vertical 15s/Pcs PCB V Cut Machine 6mm CNC Router Machine

Handy PCB V-Solt Separator PCB Separator CNC Router Machine ZM30-X

PCB V Cut Machine Introduction
● Fully-auto online V-groove Separator machine has greatly improve the quality of splitting the PCB Boards;
● It can realize the V-groove X and Y direction two-ways auotmatic slitting, it can cutting the aluminum substrate(300-1500mm), the Copper substrates, FR4 without burres.
● It can be connected to the assembly line to achieve full-auto PCB separation without manual placement；the separated boards are transported away though the assembly line,which greatly save labor cost;
● When changing product, you can directly exchange the knife die part and suction cup part without manual adjustment of the knife, which saves time greatly.

PCB V Cut Machine Operation Process
1. Machine is equipped with a lower cutting die module.PCBs are sent to the predetermined track through the PCB Loader machine;the mechanical hand moves over and uses a vacuum nozzle to transport the PCB board to the cutting die.
2. After the PCB is placed on the lower knife die module,move to the cutting position,the round knife cutting the PCB in horizontal direction,after cutting one knife,the lower knife die modelue moves to the cutting position,until finish cutting the horizontal PCBs,the rotary cylinder automatically rotates 90 degrees to cut the vertical PCB.
3. After the machine finish cutting the PCB, the knife mold and knife set exit; the picking (boards)mechanical hands moves over and sucks the PCB and the board waste edge at the same time, then moves to the waste box to put down the waste edge, then moves to PCB unloader machine to put down the PCBs on the tray and sent away by the transporation line.
4. There is an industrial vacuum cleaner under the cutting die to suck away the PCB dust.
Work in this loop.
Remarks: The individual PCB boards can be automatically placed in the charging basket (charging tray, or directly on the assembly line) according to customer requirements.

PCB V Cut Machine Specifacation

Genitec and Seprays are brands of Zhimao Automation Equipment Co., Ltd.
Zhimao Automation Equipment Co., Ltd. professionally provide customers with one-stop PCB depaneling solutions!

We produce most kinds of PCB separators. Including PCB router, laser PCB depaneling machine, V-cut, FPC/PCB punching machine,etc.

• Genitec was founded in Taiwan in 1993, and set up a subsidiary in Dongguan in 2002.Yes,that is Dongguan Zhimao Automation Equipment Co., Ltd.
• In 2003, we set up our factory in Zhejiang Province.And set up subsidiary in Suzhou in 2020.
• Genitec & Seprays: we have been specializing in PCBA separator's R&D and manufacturing for 30 years.

We gain a high reputation with high quality and service in SMT Industry. Our products sell well all over the world.

• We won the quality certification of ISO9001 in 2001, the Ministry of Economic Affairs' Small and Medium-sized Enterprise Division selected as an innovative R&D outstanding small and medium-sized enterprise.
• And won the Taichung County Government Golden Hand Award;
• We have CE certification, dozens of hardware and software patent certificates, and won a high-tech enterprise in 2020.
• We have two modern factories for over 22,000 square meters.
• We have service bases in 9 cities in China and 28 countries and regions around the world in order to provide customers with timely services and needs.
